Wanted Bridge and string retainer Westone Quantum

Post by JeffHopkins on Thu Sep 26, 2013 1:21 pm

Hi all, newbie here, I just bought a bare Westone Quantum and was wondering if anyone could point me in the right direction towards a bridge and a string retainer or compatible items. Im UK based if that helps. Cheers Jeff

JeffHopkins
Westone Nut

Number of posts : 23
Age : 50
Location : Co Durham
Registration date : 2013-09-26

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by Westbone on Tue Oct 01, 2013 10:33 am

Try this for size, it's as near as I've ever seen on Ebay. Never seen any Quantum or Rail parts on  Ebay.
http://www.ebay.co.uk/itm/231062372398?ssPageName=STRK:MESINDXX:IT&_trksid=p3984.m1436.l2649

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by JeffHopkins on Tue Oct 01, 2013 4:18 pm

Cheers for that, its the string retainer thats causing me headaches

JeffHopkins
Westone Nut

Number of posts : 23
Age : 50
Location : Co Durham
Registration date : 2013-09-26

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by Westbone on Tue Oct 01, 2013 4:41 pm

It's an easy part to make.

I'll send you dims. if you want them.

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by JeffHopkins on Tue Oct 01, 2013 4:54 pm

Cool, i actually work for an engineering firm but im a turner  haha dont do the milling and drilling, i dont actually know what the part even looks like as it was missing when i bought it.

JeffHopkins
Westone Nut

Number of posts : 23
Age : 50
Location : Co Durham
Registration date : 2013-09-26

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by Westbone on Wed Oct 02, 2013 2:58 am

Bridge is 80mm long x 40mm wide x 15mm high
string spacing 18 mm


Last edited by Westbone on Wed Oct 02, 2013 4:57 am; edited 1 time in total

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by Westbone on Wed Oct 02, 2013 4:54 am









3 clamp bolts are M5 x 12



Last edited by Westbone on Wed Oct 02, 2013 11:56 am; edited 1 time in total

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by Westbone on Wed Oct 02, 2013 5:15 am

No problem sending you that.

Mine needs a damn good clean anyway....Laughing

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by Westbone on Wed Oct 02, 2013 5:41 am

You can also use double ball ended strings on these.
Here's some on my Rail.



Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by Barry on Wed Oct 02, 2013 9:55 am

Nice one Damian.

note to self:
Gotta get me one of those nifty electronic calipers!
Can't easily read the small numbers on the rule anymore. Neutral

_________________
"A little song. A little dance. A little seltzer down your pants." -Chuckles the Clown


GUITARS : http://legend.barryeames.com/guitars.html
MUSIC/PIX/VIDEOS: http://getback.barryeames.com (including Spectrum ST)

Barry
Hero, Legend, and all round good guy

Number of posts : 6126
Age : 71
Location : Port Weller, St. Catharines, Canada
Registration date : 2009-05-01

http://www.barryeames.com

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by JeffHopkins on Wed Oct 02, 2013 1:23 pm

Thats great, thanks a lot, its almost identical to the drawing i did at work! I missed out on the bridge on ebay but i have got a bridge that is very similar and when i can post pics on here i can show you, the fretboard filth must be common on these as mines the same  haha

JeffHopkins
Westone Nut

Number of posts : 23
Age : 50
Location : Co Durham
Registration date : 2013-09-26

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by JeffHopkins on Thu Oct 03, 2013 1:33 pm

Thanks to your help I will be finishing off machining my retainer tomorrow and hopefully will post some pics of it........then.......Pickups!

JeffHopkins
Westone Nut

Number of posts : 23
Age : 50
Location : Co Durham
Registration date : 2013-09-26

Back to top Go down

Re: Wanted Bridge and string retainer Westone Quantum

Post by JeffHopkins on Fri Oct 04, 2013 12:17 pm

Ok here goes, my home made string retainer



the bridge
