Mortarmans new Project Westone

Post by mortarman120gang11c on Tue Feb 18, 2014 7:04 pm

Well I finally scored that long awaited Monarch I have been searching long and hard for. It is the Pearl White model and has the original case and all hardware is original. the project part is the previous owner somewhere in it's  life decided to do a transformation on the tonal setup etc. Thank goodness they left all the original pots in place and only made a birds nest out of the reconfigured wires. The fun as began and today I took the guitar down to inspect and clean it as well as verify the pickups and pots were still all in working order and clean them as they had been played and put up dirty and stored for a long period. The trem is original but the insert has issues that will need to be fixed. The overall body is in great shape with a slight yellow to the finish that gives it some character and the frets will need a good cleaning and overall TLC. I have the wire diagrams and also an original Dynasty and several others to reference so no problems there. I will be posting some photos of the progress from start to finish so keep an eye out for the photos and I will try to keep them updated as I go. Wish me luck and I think it will be a nice one when done. Now all I need is the Red version to go with this one.....egas never stops it seems.

mortarman120gang11c
Financial supporter

Number of posts : 706
Location : Georgia USA
Registration date : 2011-04-09

Back to top Go down

Re: Mortarmans new Project Westone

Post by The Chad on Wed Feb 19, 2014 11:51 am

Oh nice!  They are so unique.  Congrats Arthur!   cheers

Need pics or we don't believe you.

The Chad
Financial supporter

Number of posts : 2467
Location : Harrisburg, Pennsylvania
Registration date : 2011-02-01

Back to top Go down

Re: Mortarmans new Project Westone

Post by mortarman120gang11c on Wed Feb 19, 2014 6:06 pm

Well phase 1 is in progress. The Pots are out and I have been able to clean most of the disastrous solder job off all the connectors and wires as well as cleaning the trem, pickups, fret board etc. The tremolo issue has been fixed and now to address the body dings etc then begin the re wire process. All the pickups checked out good on the test meter as well as the original pots. I will need to replace the tone caps as they are old and need replacement so thank goodness for Radio Shack. More photos as the work progresses. Enjoy and wish me luck.

Cleaned up Pots


Bridge pup

Neck pup

Single Coil pup

Codes?

After the clean up you can guess how bad it was as you can see the burns from the previous solder attempts of the last owner,

Rusted tuners and headstock


Parts sitting in place at least they are all original.


Work continues so wish me luck.
