MMK45 magnet swap

Post by Westbone on Fri Nov 28, 2014 9:09 am

Swapped the magnets from a ferrite/ceramic to a Alnico II in a MMK45 awhile back.
Did a comparison test, man what an improvement!
Much clearer and defined but still with plenty of oomph! A big improvement... Smile Much better pick attack.
Well worthwhile. Just make sure you put it in the right way.

Here's the new one installed



New AII on the left, old magnet and bar on right



Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Barry on Fri Nov 28, 2014 3:43 pm

Oh deary me, just when I thought I was done working with pickups! Chores 3

Sounds like a good idea Damian. So, how's the DC resistance now compared with the usual?

_________________
"A little song. A little dance. A little seltzer down your pants." -Chuckles the Clown


GUITARS : http://legend.barryeames.com/guitars.html
MUSIC/PIX/VIDEOS: http://getback.barryeames.com (including Spectrum ST)

Barry
Hero, Legend, and all round good guy

Number of posts : 6128
Age : 71
Location : Port Weller, St. Catharines, Canada
Registration date : 2009-05-01

http://www.barryeames.com

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Fri Nov 28, 2014 8:58 pm

Same coils

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Barry on Fri Nov 28, 2014 9:32 pm

Right.
So you just created an MMK45-53?

_________________
"A little song. A little dance. A little seltzer down your pants." -Chuckles the Clown


GUITARS : http://legend.barryeames.com/guitars.html
MUSIC/PIX/VIDEOS: http://getback.barryeames.com (including Spectrum ST)

Barry
Hero, Legend, and all round good guy

Number of posts : 6128
Age : 71
Location : Port Weller, St. Catharines, Canada
Registration date : 2009-05-01

http://www.barryeames.com

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Fri Nov 28, 2014 9:50 pm

No, MMK 53' are V's..... scratch

This is a MMK45 with AII's...Try it and see what you hear..  tongue

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Sat Nov 29, 2014 11:15 am

Excuse my ignorance but how do I know which way round to fit it?

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Sun Nov 30, 2014 12:38 pm

The same orientation as the one you took out.

I usually mark the one coming out with a marker. Tipp-Ex.

and then with a third magnet find the out N/S etc. and plop it in.
No problem on a single pup but with 2 you will get the 'Peter Green' effect  when on together if your magnets are out of phase.

I also mark the 'old' magnet i.e. MMK 45 etc. otherwise you end up with a pile all stuck together not knowing what is what.

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Sun Nov 30, 2014 12:58 pm

That makes total sense, thanks man!

I should have bought the UK based A II pair when I had the chance, but ordered some from across the pond, don't like those gold artecs I put in the blue thunder, look great but sound meh.
thanks for showing this westbone!

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by grogg on Mon Dec 01, 2014 6:04 pm

DC resistance is a function of the pickup coil's wire length and strand diameter. Its like water flowing down a drain pipe, the longer and thinner the pipe the slower the water flows.
So the more turns on the coil the wire gets thinner and longer, hence higher resistance.
Changing the magnet will have no effect on the above. AC next?

grogg
Senior Member

Number of posts : 1079
Location : Cardiff
Registration date : 2008-11-28

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Tue Dec 02, 2014 11:52 pm

grogg wrote:DC resistance is a function of the pickup coil's wire length and strand diameter. Its like water flowing down a drain pipe, the longer and thinner the pipe the slower the water flows.
So the more turns on the coil the wire gets thinner and longer, hence higher resistance.
Changing the magnet will have no effect on the above. AC next?
You'll be wearing a chainmail suit next.... Laughing

Now string gauge comes into play here.

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by The Chad on Tue Dec 09, 2014 10:39 am

I love A2's on a neck pickup.

The Chad
Financial supporter

Number of posts : 2469
Location : Harrisburg, Pennsylvania
Registration date : 2011-02-01

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Tue Dec 09, 2014 8:33 pm

This particular  pup is in the neck position.

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by The Chad on Wed Dec 10, 2014 8:48 am

Thumb Up Yummy!

The Chad
Financial supporter

Number of posts : 2469
Location : Harrisburg, Pennsylvania
Registration date : 2011-02-01

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Wed Dec 10, 2014 10:01 am

Just done mine, maybe get a chance to fit them back in the blue thunder today.
I just noticed damian that yours are fitted touching the Base plate whereas I put mine up against the bobbins with spacers below,  would there be any noticeable difference?

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by The Chad on Wed Dec 10, 2014 10:35 am

I'll do this with an MMK45, too.  So discuss away my friends, I'm all ears...

The Chad
Financial supporter

Number of posts : 2469
Location : Harrisburg, Pennsylvania
Registration date : 2011-02-01

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Thu Dec 11, 2014 5:27 am

Sgt. Vimes wrote:Just done mine, maybe get a chance to fit them back in the blue thunder today.
I just noticed damian that yours are fitted touching the Base plate whereas I put mine up against the bobbins with spacers below,  would there be any noticeable difference?
The base plates none magnetic so shouldn't make too much of a difference. Try it both ways?? spacer on top/bottom.
Whats the spacer made of? wood?

Chords are a lot clearer sounding than a normal MMK45 magnet.

Depending on the amp your using also.

Main tests are through a Fender Twin. Selmer 60's T/B  50 watt into a 4x12 greenback  Hi Watt cab.
Peavey Bravo 25 watt. All amps being valve.
Using 2 identical Thunders, same new strings. Just a magnet change on one neck pup.


Don't expect it to sound like a completely different pup!
It's only the magnet.

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Thu Dec 11, 2014 12:09 pm

Wood spacers,  and I'm not expecting too much of a difference.
The amp is just a vox vt hybrid which I'm not too happy with and I'm looking for a small valve amp to replace it,  so until then I'm stuck with the muddy mess of the vt...
Not had a chance to install them yet.

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Thu Dec 11, 2014 12:47 pm

Peavey Bravo, a decent little amp if you can find one.

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Thu Dec 11, 2014 12:57 pm

Hmm,  seems to tick all the boxes, ie: fx loop,  size, wattage,  I'll bare that in mind,  thanks!
Also looking at bugera v22, but just outside my price range,  any other suggestions I'm listening ☺

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Wed Dec 31, 2014 3:02 am

How did you get on with those magnets Vimes?

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Wed Dec 31, 2014 3:50 am

I'll update this afternoon, I've had a long list of stuff to do that only just got done.
I swapped them over a couple of weeks ag.

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Wed Dec 31, 2014 7:00 am

Okidoke, all done and back in the blue thunder.
Comparing 2 T1A's original red and my blue, same strings (10-52)fitted within days of each other, same setups and going through the cleanest setting on the amp.
First impressions are:
The A-II magnets allow the poles to get much closer to the strings before that odd modulation effect.
Neck pickup is very definately softer on the wound strings and much less harsh on the unwound, still has plenty of Oomph but needs me to "dig in" to the strings a bit more to get that breakup, tis good .
Bridge pickup is just better all round, the A-II seems to have taken that horrible thick middle shouty tone away making it much clearer and "musical"...bearing in mind I never liked the mmk45 bridge in any guitar (too aggressive and Super Distortiony for me)

I'm impressed, very impressed!  I was not expecting much difference as as I forewarned by Damian, but there's more change, for the better,  than anticipated....all for just a few quid....Champion! Cheers for posting this "mod" Damian, as J.Saville said.."I DO like to fiddle around"

now to compare them with the MMK75's Smile

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Tue Jan 06, 2015 2:22 pm

Worthwhile indeed... Very Happy

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: MMK45 magnet swap

Post by Sgt. Vimes on Sat Jan 10, 2015 1:45 pm

OK, NOW I get it !
Just bought meself a virtually unused Laney LC15-110
and the mmk's with A II mags in sound unbelievable through this, makes the Vox vt15 sound like a kids toy played under a duvet!
talk about clarity! well defined crunch and just fabulous when tapped! and verry, very LOUD!!!!

cheers!

Sgt. Vimes
Financial supporter

Number of posts : 3111
Age : 45
Location : tyneside
Registration date : 2011-11-03

Back to top Go down

Re: MMK45 magnet swap

Post by Westbone on Tue Nov 22, 2016 1:28 pm

Just replying to this post as for some reason there's no cut/paste a link on the forum.

Can always move the pup further from the strings to accommodate your sound to suit at volume.

Westbone
Financial supporter

Number of posts : 4860
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down
