Another Thunder 6 string bridge

Post by Westbone on Thu Nov 05, 2015 12:20 pm

As seen in the '82 German catalogue.
Smaller baseplate.It's off an '81 Nov. guitar. The same bridge is used on the '81 Paduak pictured on the website.
Saddles are 10mm.



Here's the regular type.
Saddles are 10.5mm.

Westbone
Financial supporter

Number of posts : 4858
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Another Thunder 6 string bridge

Post by Shaky fingers on Sun Nov 15, 2015 6:09 pm

Interesting, my 84 1A has the smaller 10 mm saddles but the later back plate. Is this good, bad or just slightly odd?

Shaky fingers
Registered Member

Number of posts : 17
Registration date : 2015-09-13

Back to top Go down

Re: Another Thunder 6 string bridge

Post by Westbone on Mon Nov 16, 2015 3:59 am

Do all the holes(string) line up centered with the saddles?

Westbone
Financial supporter

Number of posts : 4858
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Another Thunder 6 string bridge

Post by Shaky fingers on Mon Nov 16, 2015 4:18 am

It looks reasonably well centered and the strings aren't noticeably going off at angle to get in the body holes...




Shaky fingers
Registered Member

Number of posts : 17
Registration date : 2015-09-13

Back to top Go down

Re: Another Thunder 6 string bridge

Post by Westbone on Mon Nov 16, 2015 4:23 am

No worries then.

What are the dims of the base plate?

Westbone
Financial supporter

Number of posts : 4858
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Another Thunder 6 string bridge

Post by Shaky fingers on Mon Nov 16, 2015 4:33 am

Its about 76mm wide and 40mm long.

Shaky fingers
Registered Member

Number of posts : 17
Registration date : 2015-09-13

Back to top Go down

Re: Another Thunder 6 string bridge

Post by iep on Sun Feb 14, 2016 5:25 am

Old thread but thought I'd resurrect rather than starting a new one.

I have the more unusual of the two bridges (10mm saddles, three mounting screws). I've noticed that the top of the bridge (closest to pickup and not screwed down) does not fit tight against the body of the guitar (floats slightly depending on string tension). I suspect this is not great for tone.

I wonder if the later five screw bridge was chosen partly to address this.

I thought I might remove the bridge and drill/countersink two additional holes at the top corners to improve bridge contact with the body.

iep

iep
Westone Nut

Number of posts : 39
Registration date : 2016-01-26

Back to top Go down
