Pantera bridge saddles too high?

Post by Fairchild on Fri Apr 22, 2016 11:26 pm

okay so I'm getting my new garage sale beauty all cleaned up and restrung, and finally get the action and intonation really close- when I notice the saddles are really high off the bridge....theres a little more adjustment to go, but they are really threaded in there good. I'm tempted to start over and raise the bridge overall height to liwer them, but I'm afraid if i get it too high it'll dive off the nocks if I get too froggy with the tremolo....enclosing pics....any advice appreciated....leave it or re-adjust? will that steeper angle make it more of a string breaker? not perfect yet but pkaying pretty goddamn sweet, but for some reason It keeps spontaneously channelling Extreme and White Lion without my approval...... Embarassed




Last edited by Fairchild on Fri Apr 22, 2016 11:37 pm; edited 1 time in total (Reason for editing : arrrgh why are there 2 of all the pictures!? cant erase spares....)

Fairchild
Westone Nut

Number of posts : 28
Age : 46
Location : Tomahawk Wisconsin usa
Registration date : 2016-03-16

Back to top Go down

Re: Pantera bridge saddles too high?

Post by corsair on Sat Apr 23, 2016 12:09 am

That looks decidely odd... as if the bridge is sitting underneath the pivot points on the bridge posts??

With these floating bridges, you can normally get them dpsitting as low as a snakes nuts just by adjusting said bridge posts... All of the Bendmaster floaters I have, have the bridge plate sitting slightly tail end low, but they are all well above the surface of the guitar...

_________________
FWIW, an after market esoteric nut is a solution to a problem that doesn't exist, and a great way to convert your money into someone else’s.

corsair
Administrator

Number of posts : 5206
Age : 57
Location : Hervey Bay, Australia.
Registration date : 2008-04-08

Back to top Go down

Re: Pantera bridge saddles too high?

Post by Barry on Sat Apr 23, 2016 11:16 am

I agree. The pix are a tad unclear but the posts don't appear to seated all the way down, and bridge knife edges are much too low. They look like they might even be on the thread?? They should be floating the indentation portion of the post, higher up.

Also, the bridge should be parallel to the body and floating just above it. This is almost hard tailed and resting on the body. Correcting those two things will then allow you to drop the height on the saddles and the pickups which also appear much too high.

_________________
"A little song. A little dance. A little seltzer down your pants." -Chuckles the Clown


GUITARS : http://legend.barryeames.com/guitars.html
MUSIC/PIX/VIDEOS: http://getback.barryeames.com (including Spectrum ST)

Barry
Hero, Legend, and all round good guy

Number of posts : 6016
Age : 71
Location : Port Weller, St. Catharines, Canada
Registration date : 2009-05-01

http://www.barryeames.com

Back to top Go down

Re: Pantera bridge saddles too high?

Post by Westbone on Sat Apr 23, 2016 3:41 pm

Here'a shot of a correctly set up one. Not a fine tune trem but the same thing without the fine tuners. This is a Bendmaster.

Slacken the springs in the trem cavity,tune up(leave the nut clamps loose) bring the trem parallel to the body. Trial + error. Saddles look ok but if you want to lower them, raise the posts. Also set your fine tuners at halfway while tuning.


Westbone
Financial supporter

Number of posts : 4778
Location : Redbridge
Registration date : 2008-12-28

http://www.chruler.com/

Back to top Go down

Re: Pantera bridge saddles too high?

Post by Fairchild on Sat Apr 23, 2016 9:11 pm

Thanks for the tips! The bridge is riding on the posts right but yeah - someone definately torqued up the springs...guess they didnt want the trem to float, but to be backstopped...once I loosened that up it rose considerably....thanks again all!

Fairchild
Westone Nut

Number of posts : 28
Age : 46
Location : Tomahawk Wisconsin usa
Registration date : 2016-03-16
